CAYIN SMP players combine industrial-grade player hardware with CAYIN SMP signage software. The first decision is usually the number of displays and whether they need clone, extended, separate or video-wall output modes.
SMP player comparison
| Item | SMP-2200 | SMP-2400 | SMP-8100 |
|---|---|---|---|
| Display outputs | 2 HDMI + VGA; controls 2 displays | 2 outputs, upgradeable to 3 | 4 HDMI outputs |
| 4K content | Supported | Supported | 1× 4K UHD or up to 4× FHD output |
| Primary fit | Compact dual-display signage | Flexible 2–3 display deployments | 3–4 display / video-wall applications |
| Scheduling / zones | CAYIN SMP workflow | CAYIN SMP workflow | CAYIN SMP workflow |
SMP-2200: compact dual-display signage
CAYIN specifies the SMP-2200 with two HDMI and one VGA outputs for controlling two screens. It supports 4K UHD video and common digital-signage content such as HTML5, images, streaming sources and scheduled zones.
SMP-2400: flexible two-to-three-display deployments
SMP-2400 is positioned between the compact 2200 and four-output 8100. CAYIN supports two displays as standard, with a paid software upgrade path for a third display. This can simplify sites where the final display count may expand.
SMP-8100: multi-display and video-wall applications
SMP-8100 provides four HDMI outputs and is specifically positioned for three- or four-display video wall applications. CAYIN states it can support one 4K UHD output or up to four Full HD outputs.
When to add a CMS server
A standalone player can schedule its own content. As the network grows, central management becomes more important for group scheduling, content updates, access control, emergency messaging and operational consistency. At that point, compare CAYIN CMS-SE and CMS-WS rather than treating the player as the entire solution.
Count independent output canvases, not only physical screens. A four-screen wall showing one stretched canvas is a different design from four displays showing independent content.
Manufacturer references
Specifications and product positioning should be reconfirmed against the current manufacturer documentation before final quotation.
